RAKwireless WisGate Edge Prime (Version 2) 8 channel Outdoor LoRaWAN Gateway RAK7240CV2 US915 LTE (EG95-NA) 716140

Product image 1
1 / 3

RAKwireless WisGate Edge Prime (Version 2) 8 channel Outdoor LoRaWAN Gateway RAK7240CV2 US915 LTE (EG95-NA) 716140

Rokland is a Gold Level distributor for RAK Wireless. Please note when comparing to price on RAK web site, RAK price is not inclusive of shipping to USA or 25% import tariffs. When buying from Rokland, items ship from USA so no additional shipping or tariffs apply.

WisGate Edge Prime Version 2 (RAK7240V2/RAK7240CV2) is RAK’s newest outdoor gateway for LoRaWAN.

It is based on the latest SX1303 LoRa core, providing better sensitivity and improved performance. The gateway is available in 8 or 16-channel versions to help you utilize the maximum of the available LoRaWAN channels in your region.

The gateway supports multi-backhaul with Ethernet, Wi-Fi, and Cellular connectivity.

There are two options regarding the supported power supply: This unit supports only PoE power, and separate SKU 716175 is equipped with a dedicated port for different power options such as DC power input (9~24VDC) and our Battery Plus.

The device comes with the newest WisGateOS 2 which provides all the existing features but adds a new design, many options, and tooltips. It comes with extension add-ons – an option to add and manage additional features catering to your needs.

The gateway can be managed remotely via the WisDM platform.

The RAK7240V2/RAK7240CV2 is suited for any use case scenario, be it rapid deployment or customization regarding UI and functionality.

The flat surface of the full metal enclosure allows your logo to be added for brand customization and recognition.

Supported LoRaWAN Network Servers: Chirp Stack v3/v4, TTN/TTS, AWS IoT Core for LoRaWAN, AWS IoT core integration, Actility LNS with Basics Station (8-channel only).

Note: The cellular option is only available for the 8-channel LoRaWAN gateway.

Features

  • Hardware
    • IP65 industrial-grade enclosure with cable glands
    • PoE (802.3af) + Surge Protection
    • Dual LoRa Concentrators for up to 16 channels
    • Backhaul: Wi-Fi, LTE (for the 8-channel version) and Ethernet
    • GPS
    • Supports DC 9~24V, RAK Battery Plus (optional)
    • External antennas for Wi-Fi, GPS, and LTE, External antenna for LoRa
    • Dying gasp
  • Software
    • WisGateOS 2
    • Extension add-ons
    • Built-in Network Server
    • LoRaWAN 1.0.3 (LoRaWAN 1.0.4 for the Built-in server is coming soon)
    • Basics Station and Packet forwarder
    • LoRa Frame filtering (node whitelisting)
    • MQTT v3.1 Bridging with TLS encryption (compatible with ChirpStack LNS)
    • Buffering of LoRa frames in Packet Forwarder mode in case of NS outage (no data loss)
    • Fine timestamping (optional)

Package Inclusion

Note: The LoRa antennas are not included in any package. They need to be bought separately, one for the 8-channel variant and two for the 16-channel variant.

    • 8 Channels with 4G*
      • 1x 8-channel device with LTE module
      • 2x LTE Antenna
      • 1x GPS Antenna
      • 1x 2.4G Wi-Fi Antenna
      • 1x PoE Injector
      • 1x Mounting Kit
      • 1x Manual

      *Version with the DC and Battery Plus support included a matching cable with connector.

      Documentation

      Warranty & Support:

      Complimentary Telephone and Email/Live Chat Support (Click Here)
      Online Technical Manuals and Instructions (Click Here)

      Sales tax is required in many states and will be added at checkout if applicable to your delivery state. Tax exempt forms can be sent to our support department.

      Return Policy: Due to the high demand for this product, all sales for this product are final and we don’t accept returns for refund unless full brand new, or defective.
